2-component epoxy resin adhesive
24 ml double syringe Weicon Epoxy Minute AdhesiveItem-no.: 1123237Supplier number: 10000133EAN: 4024596001056
PU (Packaging): 12 STKQuantity:
1 STKPackable
Description
WEICON Epoxy Minute Adhesive can be used on numerous materials such as metal, plastic, fibre-reinforced materials, ceramics, glass, stone and wood. The adhesive is suitable for construction and assembly works whenever the use of the WEICON Easy-Mix System is inefficient.
Attributes
Aluminium sandblasted
19 N/mm²
Base
Epoxy resin, unfilled
Bending strength |DIN EN ISO 178
58.0 MPa
Colour
transparent
Compressive strength|DIN EN ISO 604
9.0 MPa
Consistency
viscous
Construction material class|DIN 4102
B2
Density of the mixture
1,15 g/cm³
Dielectric strength|DIN EN 60243-1 (20°C)
20 kV/mm
E-modulus (tensile)|DIN EN ISO 527-2
2.000 - 2.500 MPa
End hardness|(100 % of strength)
24 Hours
Filling material
unfilled
Gap bridging up to max.
2 mm
Hardness (Shore D)|DIN ISO 7619
65
Manual strength|(35 % of strength)
30 Min.
Mechanically loadable after|(50 % of strength)
1 Hours
Mixing ratio by weight
1:1
PVC-hard roughened
13.0 N/mm²
Processing temperature
+10 °C to +30 °C °C
Sales bundle
Cartridge
Shrinkage
2,0 %
Steel 1.0338 sandblasted
20.0 N/mm²
Temperature resistance
-50 °C to +80 °C
Tensile strength|DIN EN ISO 527-2
40.0 MPa
Viscosity of the mixture|at +20 °C
8.500 mPa·s
