Description
Cordless Rotary Hammer with SDS plus GBH 18V-22, Muscle strain, unexpected jolts, and dust inhalation are just some of the hazards you face when drilling in concrete. Fortunately, we’ve developed the GBH 18V-22 Professional rotary hammer to make your job more comfortable. This tool is compact, light, and ergonomically designed with a well-defined centre of gravity, so you will find it easier and less tiring to handle it, especially when drilling overhead. You stay in control and there’s less impact on your hands and arms thanks to KickBack Control and Vibration Control. Connect the hammer to the GDE 18V-12 Professional dust extractor with just one click for a cleaner site while you work. And you can wrap up the job with less interruptions too – this tool combines high performance with efficient battery runtime. The GBH 18V-22 Professional rotary hammer is your tool of choice if you want a powerful but manageable power tool. It is ideal for drilling 6 mm to 10 mm holes, whether you are a plumber putting in sanitary installations or a carpenter prepping a site for a kitchen installation. Equally, if you are an electrician, you can count on this tool, particularly when drilling overhead to install lighting, lamps, and smoke detectors. The GDE 18V-12 Professional dust extractor is specially designed to facilitate overhead work. Compatible with the Bosch Professional 18V System and with the multi-brand battery alliance AMPShare. Cleaning cloth (1 619 200 413), Depth gauge (1 613 001 009), Carton box
Attributes
Battery voltage
18.0 V
Drill-Ø concrete with hammer drill
4 - 22 mm
Drill-Ø concrete with hammer drill, from
4 mm
Drill-Ø concrete with hammer drill, up to
22 mm
Gewicht exkl. Akku
2.3 kg
Impact energy (according to EPTA 05/2016)
1.9 J
Impact rate at rated speed
0 - 4675 bpm
Max. drill-Ø wood
20 mm
Max. drilling diameter in metal
13 mm
Measurement uncertainty k (chiseling in concrete)
1.5 m/s²
Measurement uncertainty k (hammer drilling in concrete)
1.5 m/s²
Nenndrehzahl, bis zu
1050 min-1
Nenndrehzahl, von
0 min-1
Optimum area of application Concrete with hammer drills
4 - 12 mm
Rated speed
0 - 1050 min-1
Tool holder
SDS plus
Verpackungsabmessungen (Breite x Länge x Höhe)
220 x 340 x 100 mm
Vibration emission value ah [Chiselling in concrete]
9.4 m/s²
Vibration emission value ah [Hammer drilling in concrete]
14.0 m/s²
Werkzeugabmessungen (Länge)
296 mm
