Bosch

Cordless rotary hammer GBH 18V-28 CF

L-BOXX 238, L-BOXX insert Bosch 0.611.921.001
Item-no.: 1636307Supplier number: 0611921001EAN: 4059952611686

Quantity: ​​ 1 STKPackable
Short-term Sourcing

Description
Cordless Rotary Hammer with SDS plus GBH 18V-28 CF, Bosch’s cordless GBH 18V-28 CF Professional is for those who desire corded performance with cordless freedom. This rotary hammer has a powerful brushless motor delivering 3.3 J impact energy from its proven striking mechanism. The easy-to-read HMI displays the tool status and allows the user to choose between three different work modes (Auto, Favorite, Soft) for perfect control in every job and the toolless, quick-change chuck reduces tool downtime. With the como module (GCY 42) installed, the GBH 18V-28 CF can connect to Bosch’s Toolbox app to further adjust the setting to suit user needs. Vibration Control, KickBack Control, and compatibility with the GDE 18V-16 for dustless drilling, provides a comprehensive range of user protection features. This rotary hammer is ideal for hammer drilling in concrete, stone, and masonry. It is compatible with all batteries and chargers in the Bosch Professional 18V System. For a dust-free and safer work environment, the GDE 18V-16 Professional dust extractor can be easily attached. Also compatible with AMPShare, the multi-brand battery alliance. It also features a storage hook and an LED light. L-BOXX 238 (1 600 A01 2G2), L-BOXX inlay (1 600 A02 SJ3), SDS plus quick-change chuck (2 608 572 213), Auxiliary handle (2 602 025 191), Depth gauge (1 613 001 009), Cleaning cloth (1 619 200 413), Grease tube (spare part number 1 615 430 010)
Attributes
Battery voltage
18.0 V
Drill-Ø concrete with hammer drill
4 - 28 mm
Drill-Ø concrete with hammer drill, from
4 mm
Drill-Ø concrete with hammer drill, up to
28 mm
Gewicht exkl. Akku
3.4 kg
Impact energy (according to EPTA 05/2016)
3.3 J
Impact rate at rated speed
4220 bpm
Max. drill-Ø wood
30 mm
Max. drilling diameter in metal
13 mm
Measurement uncertainty k (chiseling in concrete)
1.5 m/s²
Measurement uncertainty k (drilling in metal)
1.5 m/s²
Measurement uncertainty k (hammer drilling in concrete)
1.5 m/s²
Measurement uncertainty k (screwing)
1.5 m/s²
Optimum area of application Concrete with hammer drills
8 - 18 mm
Tool holder
SDS plus
Verpackungsabmessungen (Breite x Länge x Höhe)
360 x 445 x 255 mm
Vibration emission value ah [Chiselling in concrete]
9.0 m/s²
Vibration emission value ah [Drilling in metal]
2.5 m/s²
Vibration emission value ah [Hammer drilling in concrete]
14.0 m/s²
Vibration emission value ah [Screws]
2.5 m/s²
Werkzeugabmessungen (Länge)
392 mm
