Description
Cordless Drill/Driver GSR 18V-55, The cordless and powerful GSR 18V-55 Professional drill driver with brushless motor is the ideal starter tool in Bosch´s 18 V category. Tough and powerful with a high performance of 55 Nm and 1,800 RPM, it easily maximises efficiency on the jobsite, especially for work in wood and metal. Its 13-mm Roehm metal chuck makes it robust and offers an ideal power transfer for the widest range of drilling and screwdriving applications. For an extended tool lifetime and longer battery runtimes, it is equipped with a brushless motor. The drill driver is suitable for drilling in wood at up to 35 mm, in steel of up to 13 mm, and for screw diameters of up to 10 mm. It is compatible with all Bosch Professional 18 V batteries, including ProCORE18V batteries and chargers (Professional 18V System). Also compatible with AMPShare, the multi-brand battery alliance. Cardboard box
Attributes
Battery type
Lithium-ion
Battery voltage
18.0 V
Bohr-Ø Holz, max.
35 mm
Drehmoment (hart)
55 Nm
Drehmoment (weich)
28 Nm
Drill chuck clamping range, min./max.
1.5 / 13 mm
Drill-Ø steel, max.
13 mm
Gewicht exkl. Akku
1 kg
Idle speed (1st gear / 2nd gear)
0 - 460 / 0 - 1800 min-1
Idle speed, 1st gear, from
0 min-1
Idle speed, 1st gear, to
460 min-1
Idle speed, 2nd gear, from
0 min-1
Idle speed, 2nd gear, to
1800 min-1
Measurement uncertainty k (drilling in metal)
2.0 m/s²
Screw Ø, max.
10 mm
Torque (soft/hard/max.)
28/55/- Nm
Torque levels (additional)
1
Torque levels (standard)
20
Torque leves
20+1
Verpackungsabmessungen (Breite x Länge x Höhe)
263 x 323 x 114 mm
Vibration emission value ah [Drilling in metal]
1.5 m/s²
