Description
Cordless Mitre Saw BITURBO GCM 18V-254 D, Its BITURBO Brushless drive train combined with its ProCORE18V battery provides the cordless GCM 18V-254 D Professional with strong cutting performance. The detachable workpiece supports, and long table extensions allow, the mobile miter saw to easily control long materials during cutting. Even challenging cuts are done with more comfort and flexibility thanks to the dual bevel setting with the ergonomic bevel lock wheel. Cross cuts, miter cuts, and bevel cuts in wood, aluminium, and PVC plastic are the ideal application areas of the GCM 18V‐254 D Professional. It is compatible with all batteries and chargers in the Bosch Professional 18V System. For maximum power, use ProCORE18V ≥ 5.5 Ah. For sufficient runtime, 8 Ah or 12 Ah are recommended. It is also compatible with all Bosch dust extractors, GTA saw stands, and saw blades for cordless miter saws. Also compatible with AMPShare, the multi-brand battery alliance. The mobile cordless mitre saw is light and compact, and its various one- or two-handed carrying options make it easy to transport. It features greater precision thanks to the dual laser lines on the left and right side of the saw blade. 1 x circular saw blade, Standard for Wood, 254 x 30 x 2.2 mm, 48 (2 608 842 239), 2 x Workpiece support (flexibly pluggable) (1 609 B07 675), Dust bag (2 608 000 841), Clamp (1 609 B06 932)
Attributes
Battery voltage
18.0 V
Cutting capacity 0°
90 x 305 mm
Cutting capacity 45° inclination
55 x 305 mm
Cutting capacity 45° mitre
90 x 215 mm
Cutting capacity at 0°, height
90 mm
Cutting capacity at 0°, width
305 mm
Cutting capacity at 45° inclination, height
55 mm
Cutting capacity at 45° inclination, width
305 mm
Cutting capacity at 45° mitre, height
90 mm
Cutting capacity at 45° mitre, width
215 mm
Idle speed
4500 min-1
Inclination adjustment
47 ° / 47 °
Inclination adjustment, left
47 °
Inclination adjustment, right
47 °
Mitre adjustment
48 ° / 48 °
Mitre adjustment, left
48 °
Mitre adjustment, right
48 °
Saw blade bore diameter
30 mm
Saw blade diameter
254 mm
Tool dimensions (width x length x height)
500 x 787 x 632 mm
Weight
17.7 kg
