Description
Cordless Reciprocating Saw BITURBO GSA 18V-28, Thanks to the new BITURBO Brushless technology, the GSA 18V-28 offers maximum cordless cutting performance – equivalent to that of a 1,100 W corded reciprocating saw. The toolless snap-in function ensures simple, one-handed insertion and ejection of the saw blade. The GSA 18V-28 has a great power-to-weight ratio which makes it easier and less exhausting to work with in any position. The GSA 18V-28 is ideal for demolition work involving a range of materials such as metal, wood, plastic, and insulation materials. It is compatible with the Bosch Professional 18V System. Also compatible with AMPShare, the multi-brand battery alliance. The GSA 18V-28 is perfectly designed for close-to-wall cuts in an upside-down cutting position. Its ergonomic design shows a curved upper part of the handle which conveniently supports multi-grip positions. Speed can be adjusted easily and is continuously variable via a trigger. The reciprocating saw comes with an attachable rafter hook for balanced tool hanging. Cardboard box, 1 x reciprocating saw blade S 2345 X, Progressor for Wood (available separately as set of 2: 2 608 654 403), 1 x reciprocating saw blade S 123 XF, Progressor for Metal (available separately as set of 2: 2 608 654 416)
Attributes
Battery voltage
18.0 V
Cutting depth in metal profiles and metal tubes
150 mm
Cutting depth in wood
230 mm
Gewicht exkl. Akku
3.2 kg
Measurement uncertainty k (sawing wood)
1.5 m/s²
Number of strokes (1st gear / 2nd gear)
2900 min-1
Number of strokes, 1st gear
2900 min-1
Stroke length, 1st gear
28 mm
Stroke lengths
28 mm
Verpackungsabmessungen (Breite x Länge x Höhe)
185 x 500 x 108 mm
Vibration emission value ah [Sawing wood]
23.1 m/s²
