Bosch

Cordless impact wrench GDS 18V-1000

Solo device, L-Boxx Bosch 0.601.9J8.301
Item-no.: 1453369Supplier number: 06019J8301EAN: 4059952564579

Quantity: ​​ 1 STKPackable
Immediately Available

Description
Cordless Impact Wrench GDS 18V-1000, The GDS 18V-1000 Professional is the powerful 1/2" impact wrench with BITURBO Brushless technology. Its cordless freedom with outstanding power is the outcome of the high-performing brushless motor fully maximised for ProCORE18V batteries. The new impact mechanism, which is designed to deliver a maximum tightening torque of 1,000 Nm and a maximum breakaway torque of up to 1,600 Nm, provides best performance for heavy duties. Three settings offer excellent control over speed/torque for high versatility. The impact wrench is perfect for metal applications with machine screws from M10 to M24 like structural steel construction, metal assembly, pipe fitting, and for truck maintenance as well as for wood construction. It is compatible with all Bosch Professional 18 V batteries and chargers (Professional 18V system), for maximum power use ProCORE18V ≥ 5.5 Ah. Also compatible with AMPShare, the multi-brand battery alliance. The GDS 18V-1000 Professional comes with ECP and EMP, a tool status indicator, LED light, a 1/2" tool holder with friction ring, and a ladder clip. L-BOXX 136 (1 600 A01 2G0), 1/1 L-BOXX inlay for tool and charger (1 600 A02 58Y), Ladder clip (1600 A02 3G7)
Attributes
Battery voltage
18.0 V
Gewicht exkl. Akku
2.9 kg
Idle speed
0-1750 U/min
Idle speed (1st stage)
0-800 min-1
Idle speed (2nd gear)
0-1200 min-1
Idle speed (3rd gear)
0-1750 min-1
Idle speed, 1st gear, from
0 min-1
Idle speed, 1st gear, to
800 min-1
Idle speed, 2nd gear, from
0 min-1
Idle speed, 2nd gear, to
1200 min-1
Impact rate
0-2600 bpm
Impact rate (1st stage)
0-1600 bpm
Impact rate (2nd stage)
0-2400 bpm
Impact rate (3rd stage)
0-2600 bpm
Impact rate, from
0 bpm
Impact rate, up to
2600 bpm
Leerlaufdrehzahl, bis zu
1750 U/min
Leerlaufdrehzahl, von
0 U/min
Maximum breaking torque
1600 Nm
Measurement uncertainty k (tightening screws and nuts of maximum permissible size)
1.5 m/s²
Screw Ø
M 14 - M 24
Tool holder
1/2'' square
Torque adjustment range, max. 1st stange
350 Nm
Torque adjustment range, max. 2nd stange
700 Nm
Torque adjustment range, max. 3rd stange
1000 Nm
Torque adjustment range, min. 1st stange
0 Nm
Torque adjustment range, min. 2nd stange
0 Nm
Torque adjustment range, min. 3rd stange
0 Nm
Torque adjustment range, min./max. 1st stange
0/350 Nm
Torque adjustment range, min./max. 2nd stange
0/700 Nm
Torque adjustment range, min./max. 3rd stange
0/1000 Nm
Torque leves
3
Torque, max.
1000 Nm
Verpackungsabmessungen (Breite x Länge x Höhe)
360 x 445 x 155 mm
Vibration emission value ah [Tightening of bolts and nuts of maximum permissible size]
13.5 m/s²
Werkzeugabmessungen (Länge)
222 mm
