Description
Cordless Orbital Sander GSS 18V-13, The GSS 18V-13 Professional offers optimal control on larger surfaces. This is achieved through an excellent tool balance, with the centre of gravity close to the workpiece and the superior ergonomics of the palm rest and grip. Its brushless motor and Bosch’s Professional 18V System ensure fast work progress - recommended battery is the ProCORE18V 4.0Ah. It can be easily operated thanks to its intuitive concept and interchangeable sanding plate system. The GSS 18V-13 Professional is intended for basic sanding, in-between sanding, lacquer removal, and finishing surfaces. It is applicable on wood, veneer, lacquer, and filler, as well as mineral and acrylic. It is compatible with the Bosch Click & Clean dust extraction system and the Professional 18V system. Also compatible with AMPShare, the multi-brand battery alliance. It features a dust bag, speed selection and interchangeable sanding plates in three different sizes fitted with a hook-and-loop system for fastening sanding sheets. Dust bag (2 608 000 715), Base plate, 80 x 130 mm (2 608 601 447) with sanding plate (2 608 601 444), 1 x sanding sheet C470, Best for Wood + Paint, 120 (available separately as set of 10: 2 608 607 232)
Attributes
Battery voltage
18.0 V
Delta sanding plate with hook and loop fastener, length
150 mm
Delta sanding sheet with hook and loop fastener, width
100 mm
Gewicht exkl. Akku
1.1 kg
Idle speed
6000 - 10000 U/min
Leerlaufdrehzahl, bis zu
10000 U/min
Leerlaufdrehzahl, von
6000 U/min
Measurement uncertainty k (sheet material)
1.5 m/s²
Sanding plate with Velcro fastener and clamp, length
100 mm
Sanding plate with Velcro fastener and clamp, width
110 mm
Sanding plate, length
130 mm
Sanding plate, width
80 mm
Verpackungsabmessungen (Breite x Länge x Höhe)
163 x 285 x 138 mm
Vibration circle diameter
1.6 mm
Vibration emission value ah [panel material grinding]
3.4 m/s²
Vibration level at idle
12000 - 20000 min-1
Vibration rate at idle, from
12000 min-1
Vibration rate at idle, up to
20000 min-1
