GBH 2-28 rotary hammer
in a case Bosch 0.611.267.500Item-no.: 1439397Supplier number: 0611267500EAN: 3165140843607
Quantity:
1 STKPackable
Description
Rotary Hammer with SDS plus GBH 2-28, The GBH 2-28 Professional is the strongest tool within the Bosch 2 kg SDS plus corded rotary hammer category. Its robust motor delivers an outstanding 3.2 J of impact energy for high-power drilling performance. The rotary hammer also features KickBack Control for increased user protection and Vibration Control for effortless and continuous work in time-intensive applications. This tool is intended for drilling and chiselling in concrete, masonry, wood, and metal. It is compatible with various dust attachments. The GBH 2-28 Professional also features Reverse Mode, Rotation Control Clutch, Variable Speed, and Vario-Lock. Auxiliary handle (2 602 025 141), Depth stop 210 mm (1 613 001 010), Machine cloth, L-Case (1 605 438 1CR)
Attributes
Drill-Ø concrete with hammer drill
4 - 28 mm
Drill-Ø concrete with hollow core bit
68 mm
Impact energy (according to EPTA 05/2016)
3.2 J
Impact rate at rated speed
0 - 4000 bpm
Max. drill-Ø masonry, core bits
68 mm
Max. drill-Ø wood
30 mm
Max. drilling diameter in metal
13 mm
Maximum diameter in concrete with hollow core bits
68 mm
Nenndrehzahl, bis zu
900 min-1
Nenndrehzahl, von
0 min-1
Nominal input power
880 W
Opt. application range concrete, hammer drill
8 - 16 mm
Rated speed
0 - 900 min-1
Tool holder
SDS plus
Verpackungsabmessungen (Breite x Länge x Höhe)
360 x 448 x 118 mm
Voltage, electrical
230 V
Weight
2.9 kg
Werkzeugabmessungen (Länge)
216 mm
