Description
Rotary Hammer with SDS max GBH 5-40 D, The GBH 5-40 D Professional is the entry-level tool in Bosch’s SDS max corded rotary hammer category. Its lightweight and compact design makes it ideal for work in hard-to-reach places. The rotary hammer is also designed for durability, featuring robust metal components and an optimised lubrication system. Its strong motor enables the delivery of 8.5 J of impact energy for a fast drilling progress and high material removal rate. This tool is intended for drilling up to 40 mm in diameter as well as light chiselling work in concrete and stone. It is compatible with various dust attachments. The GBH 5-40 D Professional also features a Rotation Control Clutch and Speed Selection. Auxiliary handle, Grease tube (spare part number 1 615 430 010), Machine cloth, Carrying case (spare part number 1 605 438 1D1)
Attributes
Drill-Ø concrete with hammer drill
12 - 40 mm
Drill-Ø concrete with hollow core bit
40 - 90 mm
Drill-Ø concrete, break through-drill, up to
45 - 55 mm
Impact energy (according to EPTA 05/2016)
8.5 J
Impact rate at rated speed
1500 - 2900 bpm
Max. drill-Ø masonry, core bits
90 mm
Max. drilling diameter concrete
40 mm
Maximum diameter in concrete with breakthrough drills
55 mm
Maximum diameter in concrete with hollow core bits
90 mm
Minimum diameter in concrete with breakthrough drills
45 mm
Minimum diameter in concrete with hollow core bits
40 mm
Nenndrehzahl, bis zu
340 min-1
Nenndrehzahl, von
170 min-1
Nominal input power
1100 W
Opt. application range concrete, hammer drill
18 - 32 mm
Rated speed
170 - 340 min-1
Tool holder
SDS max
Verpackungsabmessungen (Breite x Länge x Höhe)
410 x 625 x 145 mm
Voltage, electrical
230 V
Weight
6.8 kg
