Rotary hammer with SDS-plus GBH 2-26
with a handyman's case Bosch 0.611.2A3.000Item-no.: 1378469Supplier number: 06112A3000EAN: 3165140859127
Quantity:
1 STKPackable
Description
Rotary Hammer with SDS plus GBH 2-26, The GBH 2-26 Professional is the all-round performer in Bosch’s SDS plus corded rotary hammer category, making it ideal for daily use. It delivers 2.7 J of impact energy, providing fast drilling and high chisel removal performance. Reliable and robust, the rotary hammer’s high-quality components also ensure a long lifetime. Its optional chisel mode enables use in a wide range of applications. This tool is intended for drilling and chiselling in concrete, masonry, wood, and metal. It is compatible with various dust attachments. The GBH 2-26 Professional also includes features such as Reverse Mode, Rotation Control Clutch, Variable Speed, and Vario-Lock. Auxiliary handle (2 602 025 141), L-Case (1 605 438 1CR), Depth stop 210 mm (1 613 001 010), Machine cloth
Attributes
Drill-Ø concrete with hammer drill
4 - 26 mm
Drill-Ø concrete with hollow core bit
16 - 68 mm
Impact energy (according to EPTA 05/2016)
2.7 J
Impact rate at rated speed
0 - 4000 bpm
Max. drill-Ø masonry, core bits
68 mm
Max. drill-Ø wood
30 mm
Max. drilling diameter in metal
13 mm
Maximum diameter in concrete with hollow core bits
68 mm
Minimum diameter in concrete with hollow core bits
16 mm
Nenndrehzahl, bis zu
900 min-1
Nenndrehzahl, von
0 min-1
Nominal input power
830 W
Opt. application range concrete, hammer drill
8 - 16 mm
Rated speed
0 - 900 min-1
Tool holder
SDS plus
Verpackungsabmessungen (Breite x Länge x Höhe)
357 x 448 x 116 mm
Voltage, electrical
230 V
Weight
2.7 kg
Werkzeugabmessungen (Länge)
377 mm
