Description
Random Orbit Sander GEX 125-1 AE, The GEX 125-1 AE Professional is Bosch's corded entry-class random orbit sander in the 125-mm category, designed for small areas and spot repair work. Its compact and ergonomic design with variable grip positions offers outstanding comfort even when working overhead. Multi-material applications are enabled by its speed preselection. Its dust box is fitted with a built-in Bosch Micro Filter System, providing an efficient dust-extraction system for practically dust-free work. This random orbit sander is intended for sanding, in-between sanding, lacquer removal and for surface finishing on various materials. It is applicable on wood, veneer, lacquer, filler, as well as mineral and acrylic surfaces. It is compatible with the Bosch Click & Clean System. The GEX 125-1 AE Professional also includes a 125-mm sanding pad fitted with a hook-and-loop system for fastening sanding paper. Carrying case, Microfilter box, 3 x sanding sheet C470, Best for Wood + Paint, 80 (available separately as set of 5: 2 608 605 069)
Attributes
Eccentricity
1.25 mm
Idle speed
7500 - 12000 min-1
Leerlaufdrehzahl, bis zu
12000 min-1
Leerlaufdrehzahl, von
7500 min-1
Measurement uncertainty k (sanding solid wood)
1.5 m/s²
Nominal input power
250 W
Sanding attachment
Velcro fastener
Sanding disc diameter
125 mm
Verpackungsabmessungen (Breite x Länge x Höhe)
301 x 349 x 166 mm
Vibration circle diameter
2.5 mm
Vibration emission value ah [Sanding solid wood]
5.0 m/s²
Vibration rate
15000 - 24000 min-1
Vibration rate, from
15000 min-1
Vibration rate, up to
24000 min-1
Voltage, electrical
230 V
Weight
1.3 kg
Werkzeugabmessungen (Länge)
227 mm
