Description
FlexiClick Adapter GFA 12-H, The GFA 12-H Professional is the world´s first 12 V hammer attachment. It offers highest flexibility by turning the FlexiClick drill driver into a SDS plus rotary hammer. This makes it the only 12 V drill driver which is ready for effortless hammer drilling into concrete, making use of an impact energy of 0.9 J. The GFA 12-H is part of the 12 V FlexiClick System, consisting of various easy-to-change attachments. It covers many different applications to make the craftsmen’s life easier. The Bosch Professional FlexiClick System – perfectly equipped for a professional job. The GFA 12-H is suitable for hammer drilling up to 10 mm into concrete and up to 16 mm into masonry and stone. It is compatible with the 12 V FlexiClick drill drivers GSR 12V-35 FC and GSR 12V-15 FC. For best working progress, use GSR 12V-35 FC. Auxiliary handle, Depth stop (spare part number 1 613 001 009), Cardboard box
Attributes
Impact energy, max.
0.9 J
Max. drill-Ø in concrete
10 mm
Size
145x55x55 mm
Tool holder
SDS plus
Verpackungsabmessungen (Breite x Länge x Höhe)
128 x 230 x 77 mm
Weight
0.8 kg
Werkzeugabmessungen (Länge)
145 mm
