Riegler

Glycerine manometer

AG 1/4", D63 mm, 0-25 bar, max 60°C Metal, bottom connection
Item-no.: 1116698Supplier number: 709EAN: 4047322113922

Quantity: ​​ 1 STKPackable
Item available in 47 variants:
Immediately Available

Description
Glycerine pressure gauge with metal housing, Connection radial bottom, G 1/4, Goods class 1. 6, Measurement range 0 - 25 bar, Ø 63Glycerine-filled bourdon-tube pressure gauge. For measurements in areas with high, dynamic pressure loads and vibration levels. Suitable for gaseous or liquid media which do not corrode copper alloy, do not have high viscosity and do not crystallise.
Attributes
Ambient temperature max.
60 °C
Ambient temperature min.
-20 °C
Connection
G 1/4
Connection position
Radial bottom
Diameter
63 mm
Flange ring
CrNi steel
Housing
Pressed brass
Lower / upper measuring range limit
Overpressure
Material process connection
Copper alloy
Measuring element
Copper alloy
Measuring range max. bar
25
Measuring range min. bar
0
Medium temperature max.
60 °C
Pointer movement
Copper alloy
Quality class
1.6
Riegler article number
102175
Scale graduation in the bar range
1 bar
Type
213.40
Viewing window
Acrylic glass
