Description
Hand-Held Circular Saw GKS 65 GCE+FSN 1400, The GKS 65 GCE Professional circular saw is the ideal choice for guided cuts in a wide range of materials. The powerful and precise circular saw has a 1,800 W motor and achieves a cutting depth of 65 mm. For exact cuts, it has been optimised for use with the Bosch guide rail system. It produces an even sawing progress in a wide variety of materials thanks to the speed selection The circular saw is specially designed for tough tasks and saws various materials such as derived lumber products like OSB, plywood, or MDF. It is compatible with the Bosch guide rail system as well as the guide rail systems of Mafell, Festool, and Makita. The GKS 65 GCE Professional features an air blower, aluminium die-cast footplate, dust port connector, constant speed, soft start and spindle lock. 1 x circular saw blade, Speedline Wood, 190 x 30 x 2.6 mm, 12 (2 608 640 800), L-BOXX 238 (1 600 A01 2G2), 1 x guide rail FSN 1400 (1 600 A02 1AV)
Attributes
Guide rail compatible
ja
Idle speed
2300 - 5000 min-1
Leerlaufdrehzahl, bis zu
5000 min-1
Leerlaufdrehzahl, von
2300 min-1
Max. cutting capacity in wood (45°)
48 mm
Max. cutting capacity in wood (90°)
65 mm
Measurement uncertainty k (wood sawing)
1.5 m/s²
Nominal input power
1800 W
Saw blade bore diameter
30 mm
Saw blade diameter
190 mm
Spannung, elektrisch
230 V
Verpackungsabmessungen (Breite x Länge x Höhe)
575 x 1955 x 286 mm
Vibration emission value ah [Wood sawing]
3.0 m/s²
Weight
5.2 kg
