Item-no.: 1177312Supplier number: 0601530103EAN: 3165140415026
Quantity:
1 STKPackable
Description
Nibbler GNA 2,0, The GNA 2,0 Professional corded nibbler is one of Bosch's real all-rounder tools in the 500 W category. Its swivel-mounted die plate supports perfect manoeuvrability in each direction as well as in corners. The nibbler is ideal for cutting multiple metal materials of up to 2.0 mm and excellent for making inner cutouts. Hex key WAF 2.5 (spare part number 1 907 950 003), Die plate (2 608 639 900), Punch (2 608 639 013)
Attributes
Cutting capacity aluminium (200 N/mm²), max.
2.5 mm
Cutting capacity steel (400 N/mm²), max.
2.0 mm
Cutting capacity steel (600 N/mm²), max.
1.4 mm
Cutting capacity steel (800 N/mm²), max.
1.0 mm
Cutting track width
6 mm
Idle stroke rate
2400 min-1
Machinable material
Steel up to 400 N/mm² at 2.0 mm
Measurement uncertainty k (cutting sheet metal)
1.5 m/s²
Nominal input power
500 W
Number of strokes, load
1500 min-1
Output power
270 W
Pre-drilling for internal cut-outs
16 mm
Schwingungsemissionswert ah
9.0 m/s²
Smallest radius
3 mm
Verpackungsabmessungen (Breite x Länge x Höhe)
170 x 325 x 87 mm
Vibration emission value ah [cutting sheet metal]
9.0 m/s²
Weight
2.0 kg
Werkzeugabmessungen (Länge)
275 mm
