Rodent
GNA 3.5 Bosch 0.601.533.103Item-no.: 1168836Supplier number: 0601533103EAN: 3165140075947
Quantity:
1 STKPackable
Description
Nibbler GNA 3,5, The corded GNA 3-5 Professional is Bosch´s strongest nibbler in the 620 W category, and is ideal for deep cuts. Clean cutting is enabled by its high torque motor and a reduced stroke rate. It is perfect for cutting various metal materials of up to 3.5 mm and is excellent for inner cutouts. Hex key WAF 4 (1 907 950 005), Auxiliary handle (2 602 025 075), Die plate (2 608 639 026), Punch (2 608 639 025), Supporting arm (2 607 001 190)
Attributes
Cutting capacity aluminium (200 N/mm²), max.
4.0 mm
Cutting capacity steel (400 N/mm²), max.
3.5 mm
Cutting capacity steel (600 N/mm²), max.
2.4 mm
Cutting capacity steel (800 N/mm²), max.
1.6 mm
Cutting track width
6 mm
Idle stroke rate
1000 min-1
Machinable material
Steel up to 400 N/mm² at 3.5 mm
Measurement uncertainty k (cutting sheet metal)
1.5 m/s²
Nominal input power
620 W
Number of strokes, load
670 min-1
Output power
340 W
Pre-drilling for internal cut-outs
41 mm
Schwingungsemissionswert ah
7.0 m/s²
Smallest radius
70 mm
Verpackungsabmessungen (Breite x Länge x Höhe)
200 x 348 x 100 mm
Vibration emission value ah [cutting sheet metal]
7.0 m/s²
Weight
3.5 kg
Werkzeugabmessungen (Länge)
292 mm
