Digital inclinometer
GIM 120 Bosch 0.601.076.800Item-no.: 1269790Supplier number: 0601076800EAN: 3165140803236
Quantity:
1 STKPackable
Description
Digital Inclinometer GIM 120, Longer for maximum precision, Measures precise tilts in degrees, percent or millimetres/metres, Direction arrows and audible signals at 0° and 90° for easy alignment, Measured values automatically turn on the display when working overhead, Protective Bag, 4 x 1.5 V LR6 battery (AA)
Attributes
Length (battery)
120 cm
Measuring accuracy electronics 0°/90°
± 0.05°
Measuring accuracy electronics at 1 - 89°
± 0.2°
Measuring accuracy vials
± 0.057° = ± 1 mm/m
Measuring range
0 - 360° (4 x 90°)
Operating time inclination measurement approx.
200 h
Units of measurement
°, %, mm/m
Weight approx.
1.3 kg
