Tracking device
D-Tect 200 C Alkaline K Bosch 0.601.081.600Item-no.: 1571998Supplier number: 0601081600EAN: 3165140988148
Quantity:
1 STKPackable
Description
Detector Wallscanner D-tect 200 C, The D-tect 200 C Professional detects all common objects and illustrates them clearly, while making documentation easy. Equipped with Bosch Radar Technology and an improved user interface, it stands for safer and more precise construction work. Multiple views allow for conveniently choosing the best option for different applications, such as Spot View, that makes detection in hard-to-reach locations especially easy. To provide solid evidence, the wallscanner´s innovative screenshot feature enables quick documentation. The D-tect 200 C Professional supports both indoor and outdoor jobs, prevents damage during drilling, and measures concrete coverage. The wallscanner detects objects in depths up to 20 cm and indicates the object´s depth. Pouch, 4 x 1.5 V LR6 battery (AA), Battery adapter (1600A017HF/1600A017HH), USB-C™ Cable, Hand strap
Attributes
Accuracy
± 5 mm* (* plus application-dependent deviation)
Battery voltage
12 V
Bosch radar technology
ja
Detection depth, dry concrete, max.
200 mm
Detection depth, other wall types, max.
80 mm
Detection depth, wooden substructures, max.
38 mm
Detection depth, young concrete, max.
60 mm
Documentation via
USB-C
Dust and splash protection
IP 5X
Erfassbare Objekte
wasserführende Kunststoffrohre
Material identification
Non-metallic material
Max. locating depth
200 mm
Power supply
4 x 1.5 V LR6 (AA)
Updateable
ja
Views
Spot view
Wall types
Young concrete
Weight, approx.
0.7 kg
