Description
Mitre Saw GCM 10 GDJ, The GCM 10 GDJ Professional mitre saw represents the union of state-of-the-art performance and revolutionary design. Bosch’s Axial-Glide™ system makes for consistent precision and smooth gliding action, even in limited working spaces. Safe and comfortable: upfront bevel controls ensure quick and easy adjustment, without the risk of having to reach behind the saw. The saw head can be locked in the cut position, achieving the maximum cutting capacity for chopcuts. Ideally used on hard wood, soft wood, wood composites, MDFs, as well as dimensional and engineered lumber, this saw is the perfect choice for all trimming tasks in jobs like carpentry, remodelling, window installation, and cabinet building. The saw is compatible with the following Bosch stands: GTA 2500 Compact, GTA 2500 W, GTA 2600, and GTA 380 The GCM 10 GDJ Professional also features a large easy-to-read bevel and mitre scale as well as tall fences and machined squares for optimal material support. 1 x circular saw blade, Expert for Wood, 254 x 30 x 2.4 mm, 60 (2 608 642 530), Clamp (1 609 B06 203), Dust bag (spare part number 1 609 B00 506)
Attributes
Cutting capacity 0°
80 x 306 mm
Cutting capacity 45° inclination
54 x 296 mm
Cutting capacity 45° mitre
80 x 216 mm
Cutting capacity at 0°, height
80 mm
Cutting capacity at 0°, width
306 mm
Cutting capacity at 45° inclination, height
54 mm
Cutting capacity at 45° inclination, width
296 mm
Cutting capacity at 45° mitre, height
80 mm
Cutting capacity at 45° mitre, width
216 mm
Idle speed
5000 min-1
Inclination adjustment
52 ° / 60 °
Inclination adjustment, left
52 °
Inclination adjustment, right
60 °
Mitre adjustment
47 ° / 47 °
Mitre adjustment, left
47 °
Mitre adjustment, right
47 °
Nominal input power
2000 W
Saw blade bore diameter
30 mm
Saw blade diameter
254 mm
Tool dimensions (width x length x height)
813 x673 x521 mm
Weight
31.6 kg
