Polyurethane hose PUR blue
NW12/9-very flexible -40 to +60°CItem-no.: 1120617Supplier number: 259.20 B-100EAN: 4047322399661
PU (Roll): 100 MeterPU (Packaging): 100 MeterQuantity:
100 MeterPackable
Item available in 59 variants:
Price and stock visible after login
Description
Polyurethane hose (PUR), Temperature -20 °C to 60 °C, Hose Ø 12x1.5 mm, PN at 23 °C max. 8 bar, blue, Roll of 100 m in a paper box. Polyurethane hoses are renowned for their extreme flexibility and correspondingly narrow bending radius across a wide temperature range. They are more flexible even than LD-PE hoses and exhibit good abrasion resistance, very good low-temperature flexibility, only minimal permanent deformation when subjected to long-term stresses as well as good resistance to the majority of oils, greases, aliphatic hydrocarbons and oxygen. Main applications: - Pneumatic and hydraulic (miniature hydraulics) lines - Mechanical engineering - Engine construction - Instrumentation and control - Ideal for use with unions, as externally calibrated
Attributes
Colour
blue
Hose-Ø inside
9 mm
Hose-Ø outer
12 mm
Material
Polyurethane (PUR)
Max. operating pressure at 23 °C
8 bar
Riegler article number
113711
Roll length
100 m
Temperature range max.
60 °C
Temperature range min.
-20 °C
Wall thickness
1,5 mm
