Item available in 49 variants:
Diameter (D): 28.00 mm Total length mm: 400 mm
xDiameter (D): 24.00 mm
Total length mm: 400 mm
Diameter (D): 10.00 mm
Total length mm: 400 mm
Diameter (D): 6.00 mm
Total length mm: 400 mm
Diameter (D): 10.00 mm
Total length mm: 400 mm
Diameter (D): 22.00 mm
Total length mm: 400 mm
Diameter (D): 30.00 mm
Total length mm: 400 mm
Diameter (D): 20.00 mm
Total length mm: 400 mm
Diameter (D): 30.00 mm
Total length mm: 400 mm
Diameter (D): 8.00 mm
Total length mm: 400 mm
Diameter (D): 18.00 mm
Total length mm: 400 mm
Total length mm: 400 mm
Diameter (D): 28.00 mm
Total length mm: 400 mm
Diameter (D): 14.00 mm
Total length mm: 400 mm
Diameter (D): 20.00 mm
Total length mm: 400 mm
Diameter (D): 28.00 mm
Total length mm: 400 mm
Diameter (D): 26.00 mm
Total length mm: 400 mm
Diameter (D): 16.00 mm
Total length mm: 400 mm
Diameter (D): 25.00 mm
Total length mm: 400 mm
Diameter (D): 16.00 mm
Total length mm: 400 mm
Diameter (D): 24.00 mm
Total length mm: 400 mm
Diameter (D): 12.00 mm
Total length mm: 400 mm
Total length mm: 400 mm
Diameter (D): 26.00 mm
Total length mm: 400 mm
Diameter (D): 22.00 mm
Total length mm: 400 mm
Diameter (D): 14.00 mm
Total length mm: 400 mm
Diameter (D): 16.00 mm
Total length mm: 600 mm
Diameter (D): 12.00 mm
Total length mm: 600 mm
Diameter (D): 20.00 mm
Total length mm: 600 mm
Diameter (D): 26.00 mm
Total length mm: 600 mm
Diameter (D): 24.00 mm
Total length mm: 600 mm
Diameter (D): 20.00 mm
Total length mm: 600 mm
Diameter (D): 18.00 mm
Total length mm: 600 mm
Diameter (D): 16.00 mm
Total length mm: 600 mm
Diameter (D): 14.00 mm
Total length mm: 600 mm
Diameter (D): 30.00 mm
Total length mm: 600 mm
Diameter (D): 22.00 mm
Total length mm: 600 mm
Diameter (D): 10.00 mm
Total length mm: 600 mm
Diameter (D): 22.00 mm
Total length mm: 600 mm
Diameter (D): 28.00 mm
Total length mm: 600 mm
Diameter (D): 6.00 mm
Total length mm: 600 mm
Diameter (D): 18.00 mm
Total length mm: 600 mm
Diameter (D): 12.00 mm
Total length mm: 600 mm
Diameter (D): 14.00 mm
Total length mm: 600 mm
Diameter (D): 26.00 mm
Total length mm: 600 mm
Diameter (D): 30.00 mm
Total length mm: 600 mm
Diameter (D): 8.00 mm
Total length mm: 600 mm
Diameter (D): 28.00 mm
Total length mm: 600 mm
Diameter (D): 10.00 mm
Total length mm: 600 mm
Diameter (D): 24.00 mm
Total length mm: 600 mm
Description
The Installation Drill Bit is very robust for formwork. Its drill bit and shank end are screw-connected, which ensures a low risk of breakage and improves smooth-running operations. Furthermore, its tapered flute, offset drill bit and shank ends prevent jamming even in moist wood, while maintaining enough power to cut through embedded nails. Equipped with an extra-long shank, the bit delivers versatile drilling in multilayer building materials or sandwich materials, e.g. for building trade (formwork) and for interior fitting work, plumbing, heating and electrical installation. It is suitable for use on formwork, boards, planks, beams, plasterboard, light building materials, insulations and metal, e.g. metal plates, materials sandwiched with steel, aluminium or profile sheet. Made from HSS (high-speed steel), the Installation Drill Bit is manufactured to DIN 7490. It has a drill bit tip with chisel edge of 118 degrees.
Attributes
Arbeitslänge
100 mm
Diameter (D)
28.00 mm
Overall length (L2)
400 mm
Schaftdurchmesser (d) mm
11 mm
Shaft diameter (d)
11 mm
Total length mm
400 mm
