Hose clamp DIN 3017
20-32 mm, band 9 mm, W2 1.4016 Worm threadItem-no.: 1121401Supplier number: 158 EEAN: 4047322030083
PU (Packaging): 50 PieceQuantity:
1 PiecePackable
Item available in 13 variants:
Price and stock visible after login
Description
Worm thread hose clamp, Chrome steel 1.4016 (W2), according to DIN 3017, Clamping range 20.0 - 32.0 mm, Belt width 9.0 mm. Worm drive type. For all standard applications where high clamping forces are normally distributed. Hexagon-head screw a/f 7, with integrated cross-tip, bright galvanised steel, passivated blue.
