Swivelling probe

Application: - Diagnosis and documentation of cavities for damage assessment · Improved accuracy of detail thanks to HD camera · Smaller probe diameter 3.9 mm · Compatible with basic unit 4812-23G and 4812-11G · Including control unit to operate articulation, video recording, brightness control · Bending radius approx. 35 mm (-30% compared to conventional designs) · High mobility due to bilateral articulation · Full swivel up to 180° on both sides enables e.g. a real reverse view onto valves in the cylinder head · Front camera · Twofold dimmable LED light source · Digital interface to basic unit: USB-C · Viewing angle (FOV): 90° · Depth of focus (DOV): 10 – 100 mm · Resolution: HD 1280(H) x 720(V) pixels · Compression format: H.264 · Operating temperature: -10°C to 60°C · Probe protection rating: IP67 · Weight: 307 g · Improved accuracy of detail thanks to HD camera · Diagnosis of cavities for damage assessment · Image format: Jpeg · Video format: MOV · Protection rating probe: IP67 (when connected) · Probe cable: 1 m · Dimensions: 35.4 x 51.1 mm 2589 mm (W x H x L).
