Riegler

Standard pressure gauge

AG 1/4", 0-10 bar, D 50 mm Sheet steel, bottom connection
Item-no.: 1116561Supplier number: 106EAN: 4047322012485

Quantity: ​​ 1 STKPackable
Item available in 47 variants:
Immediately Available

Description
Standard pressure gauge, Single scale bar, Connection radial bottom, G 1/4, Goods class 1. 6, Measurement range 0 - 10 bar, Ø 50Bourdon-tube pressure gauge in standard design. Suitable for gaseous or liquid media which do not corrode copper alloy, do not have high viscosity and do not crystallise.
Attributes
Ambient temperature max.
60 °C
Ambient temperature min.
-20 °C
Connection
G 1/4
Connection position
Radial bottom
Description
Pressure gauge Ø 50 mm, G 1/4 AG, 0 - 10 bar
Diameter
50 mm
Housing
Sheet steel
Lower / upper measuring range limit
Overpressure
Material process connection
Copper alloy
Measuring element
Copper alloy
Measuring range max. bar
10
Measuring range min. bar
0
Medium temperature max.
60 °C
Pointer movement
Copper alloy
Quality class
1.6
Riegler article number
101408
Scale graduation in the bar range
0,5 bar
Type
111.10
Viewing window
Crystal clear plastic
