Jigsaw
GST 90 BE Bosch 0.601.58F.000Item-no.: 1572025Supplier number: 060158F000EAN: 3165140602839
Quantity:
1 STKPackable
Description
Jigsaw GST 90 BE, The GST 90 BE Professional corded jigsaw offers reliable entry-level performance. Its bow handle with variable speed trigger enables steady day-to-day work. Changing saw blades is made easy by the jigsaw’s tool-free Bosch SDS-system. Additionally, its reliable 650 W motor produces fast work results. This tool is intended for curved cutting in solid wood, chipboards, and wood composites. It is compatible with the Bosch Click & Clean System as well as with other Bosch vacuum cleaners. The GST 90 BE Professional can also make beveled cuts and features a blower, orbital action, and speed selection. Dust extraction set (spare part number 1 619 P07 167), Carrying case, Hex key WAF 5 (spare part number 1 907 950 006), Anti-splinter guard (spare part number 2 601 016 065), 1 x jigsaw blade T 144 D, Speed for Wood (available separately as set of 3: 2 608 630 560)
Attributes
Cable length
2.5 m
Cutting depth in aluminium
20 mm
Cutting depth in steel
10 mm
Cutting depth in unalloyed steel
10 mm
Cutting depth in wood
90 mm
Measurement uncertainty k (sawing metal plates)
1.5 m/s²
Measurement uncertainty k (sawing wood)
1.5 m/s²
Nominal input power
650 W
Number of strokes at idle, from
500 min-1
Number of strokes at idle, up to
3100 min-1
Number of strokes at idling speed
500 - 3100 min-1
Verpackungsabmessungen (Breite x Länge x Höhe)
105 x 350 x 298 mm
Vibration emission value ah [Sawing sheet metal]
6.5 m/s²
Vibration emission value ah [Sawing wood]
8.5 m/s²
Voltage, electrical
230 V
Weight
2.6 kg
Werkzeugabmessungen (Länge)
332 mm
