Description
Angle Grinder GWS 27-230 JR, Finding an angle grinder with high performance that is comfortable and easy to use can be a challenge. The GWS 27-230 JR Professional’s superior power gets tough jobs done faster. Its powerful 2,700W motor boosts efficiency by removing more material in less time. Convenient to handle, you can rotate the grinder's main handle by 90° at the flick of a switch. So you get the perfect grip – whether you’re grinding or cutting. The interlock function ensures that the tool cannot start until the main handle is fully rotated by 90° and locked-in with a "click". In addition, the GWS 27-230 JR Professional comes with KickBack Control and Vibration Control. The GWS 27-230 JR Professional is your go-to tool for grinding and cutting metal, stone and tiles. It offers restart protection, has a soft start and a convenient keyless guard for grinding applications. Compatible with the GDE 230 FC-T Professional dust attachment. Cardboard box, Vibration Control auxiliary handle (2 608 900 000), Quick adjustment protective guard (2 605 510 281), Backing flange (1 605 703 099), Locking nut (1 603 340 040), Two-hole spanner (1 607 950 048)
Attributes
Borehole, Ø
22.2 mm
Disc Ø
230 mm
Grinding spindle thread
M14
Idle speed
5200 - 6500 min-1
Leerlaufdrehzahl, bis zu
6500 min-1
Leerlaufdrehzahl, von
5200 min-1
Main handle
D-handle
Measurement uncertainty k (sanding with sanding sheet)
1.5 m/s²
Measurement uncertainty k (surface grinding (roughing ))
1.5 m/s²
Nenneingangsleistung
2700 W
Output power
2700 W
Pot brush, Ø
100 mm
Rated idle speed
6500 min-1
Sanding cup, Ø
110 mm
Spannungsbereich, bis zu
240 V
Spannungsbereich, von
220 V
Verpackungsabmessungen (Breite x Länge x Höhe)
190 x 600 x 140 mm
Vibration emission value ah [sanding with sanding sheet]
4.5 m/s²
Vibration emission value ah [surface grinding (roughing)]
6.5 m/s²
Voltage range
220 - 240 V
Voltage, electrical
230 V
Weight
6.3 kg
Werkzeugabmessungen (Länge)
530 mm
