Description
Angle Grinder GWS 9-125 S, The GWS 9-125 S Professional small angle grinder features a strong motor, speed selection and optimal tool control. Its strong 900 W motor facilitates fast work progress. This small angle grinder has optimal tool control due its small grip size and ergonomic design. Furthermore, its speed selection feature produces perfect working results in a variety of materials. The GWS 9-125 S is intended for cutting and grinding metal, tiles, and bricks. It is compatible with dust attachment GDE 125 EA-T Professional. The GWS 9-125 S Professional als features protection guard and restart protection. Backing flange, Cardboard box, Protective guard, Locking nut, Auxiliary handle, Two-hole spanners
Attributes
Disc Ø
125 mm
Grinding spindle thread
M14
Idle speed
2800 - 11000 min-1
Leerlaufdrehzahl, bis zu
11000 min-1
Leerlaufdrehzahl, von
2800 min-1
Measurement uncertainty k (sanding with sanding sheet)
1.5 m/s²
Measurement uncertainty k (surface grinding (roughing ))
1.5 m/s²
Nominal input power
900 W
Output power
450 W
Switch
Locking switch
Verpackungsabmessungen (Breite x Länge x Höhe)
128 x 362 x 122 mm
Vibration emission value ah [sanding with sanding sheet]
7.5 m/s²
Vibration emission value ah [surface grinding (roughing)]
7.5 m/s²
Voltage range
220 - 240 V
Voltage range, from
220 V
Voltage range, up to
240 V
Weight
1.9 kg
Werkzeugabmessungen (Länge)
280 mm
