Description
Angle Grinder GWS 17-125 S, The GWS 17-125 S Professional provides high power, overload capability, and improved dust protection by air inlets at the backside of the tool with removable dust filter stand for maximum productivity. Thanks to its significantly small grip size, the angle grinder with a powerful 1,700 W motor allows better convenience while working in the metal industry. For a high user protection, it features KickBack Control, Restart Protection, and a Vibration Control side handle. The GWS 17-125 S Professional is best for grinding metal or welding seams and cutting metal, concrete, bricks, and tiles. It is compatible with Bosch’s dust extraction systems GDE 125 EA-T Professional and GDE 115 / 125 FC-T Professional. The small angle grinder features Constant Speed, Soft Start, and Overload Protection. Vibration Control auxiliary handle (2 608 900 000), Protective guard (1 605 510 365), Protective clip-on cutting guard metal (2 608 000 756), Dust filter (2 607 432 053), Two-hole spanner (1 607 950 043), Backing flange (1 605 703 099), Locking nut (1 603 340 040), Cardboard box
Attributes
Borehole, Ø
22.2 mm
Disc Ø
125 mm
Grinding spindle thread
M14
Idle speed
2800 - 11500 min-1
Leerlaufdrehzahl, bis zu
11500 min-1
Leerlaufdrehzahl, von
2800 min-1
Main handle
Bar handle
Measurement uncertainty k (sanding with sanding sheet)
1.5 m/s²
Measurement uncertainty k (surface grinding (roughing ))
1.5 m/s²
Nominal input power
1700 W
Verpackungsabmessungen (Breite x Länge x Höhe)
130 x 390 x 160 mm
Vibration emission value ah [sanding with sanding sheet]
2.4 m/s²
Vibration emission value ah [surface grinding (roughing)]
5.2 m/s²
Voltage range
220 - 240 V
Voltage range, from
220 V
Voltage range, up to
240 V
Voltage, electrical
230 V
Weight
2.2 kg
Werkzeugabmessungen (Länge)
327 mm
