Beschrijving
Cordless Rotary Hammer with SDS plus GBH 18V-22, Muscle strain, unexpected jolts, and dust inhalation are just some of the hazards you face when drilling in concrete. Fortunately, we’ve developed the GBH 18V-22 Professional rotary hammer to make your job more comfortable. This tool is compact, light, and ergonomically designed with a well-defined centre of gravity, so you will find it easier and less tiring to handle it, especially when drilling overhead. You stay in control and there’s less impact on your hands and arms thanks to KickBack Control and Vibration Control. Connect the hammer to the GDE 18V-12 Professional dust extractor with just one click for a cleaner site while you work. And you can wrap up the job with less interruptions too – this tool combines high performance with efficient battery runtime. The GBH 18V-22 Professional rotary hammer is your tool of choice if you want a powerful but manageable power tool. It is ideal for drilling 6 mm to 10 mm holes, whether you are a plumber putting in sanitary installations or a carpenter prepping a site for a kitchen installation. Equally, if you are an electrician, you can count on this tool, particularly when drilling overhead to install lighting, lamps, and smoke detectors. The GDE 18V-12 Professional dust extractor is specially designed to facilitate overhead work. Compatible with the Bosch Professional 18V System and with the multi-brand battery alliance AMPShare. L-BOXX 238 (1 600 A01 2G2), 1/1 L-BOXX inlay for GBH 18V-22 + GDE 18V-12 (1 600 A02 NS8), 2 x ring brush (1 600 A00 D2R), 2 x battery GBA 18V 4.0Ah (1 600 Z00 038), Quick charger GAL 18V-40 Professional (1 600 A01 9RJ), Dust extraction system GDE 18V-12 Professional (1 600 A02 8H6)
Specificaties
Aantal slagen bij nominaal toerental
0 - 4675 bpm
Accuspanning
18.0 V
Boor-Ø beton met hamerboor
4 - 22 mm
Boor-Ø beton met hamerboor, tot
22 mm
Boor-Ø beton met hamerboor, van
4 mm
Gereedschapshouder
SDS plus
Gewicht exkl. Akku
2.3 kg
Max. boor-Ø hout
20 mm
Max. boordiameter metaal
13 mm
Meetonzekerheid k (beitelen in beton)
1.5 m/s²
Meetonzekerheid k (hamerboren in beton)
1.5 m/s²
Nenndrehzahl, bis zu
1050 min-1
Nenndrehzahl, von
0 min-1
Nominale toerental
0 - 1050 min-1
Optimaal toepassingsgebied Beton met hamerboren
4 - 12 mm
Slagenergie (volgens EPTA 05/2016)
1.9 J
Trillingsemissie ah [beitelen in beton]
9.4 m/s²
Trillingsemissie ah [hamerboren in beton]
14.0 m/s²
Verpackungsabmessungen (Breite x Länge x Höhe)
360 x 445 x 256 mm
Werkzeugabmessungen (Länge)
296 mm
