Beschrijving
Cordless Rotary Hammer with SDS plus GBH 18V-26F, The GBH 18V-26 F Professional with quick-change chuck is the universal performer in Bosch’s SDS plus cordless rotary hammer category, making it perfect for daily use. An optional GDE 18V-16 Professional dust extraction unit integrates with the hammer, providing a self-contained HEPA dust solution for maximum mobility. The rotary hammer also features KickBack Control and Electronic Precision Control (EPC) for better tool handling and increased user protection. Its powerful motor delivers 2.6 J of impact energy for fast material removal rates. This tool is intended for drilling and chiselling in concrete, masonry, wood, and metal. It is compatible with various dust attachments as well as all Bosch Professional 18 V batteries and chargers (Professional 18V System). Also compatible with AMPShare, the multi-brand battery alliance. The GBH 18V-26 F Professional also includes various additional features such as Constant Speed, a Brushless Motor, Electronic Motor Protection (EMP), as well as an LED light, Rotation Control Clutch, Variable Speed, Vario Lock, and Vibration Control. Auxiliary handle (2 602 025 141), L-BOXX 238 (1 600 A01 2G2), Depth stop 210 mm (1 613 001 010), Quick charger GAL 1880 CV (1 600 A00 B8G), Quick change chuck 13 mm (2 608 572 212), SDS plus quick-change chuck (2 608 572 213), Dust extraction system GDE 18V-16 Professional (1 600 A00 51M), 1/1 L-BOXX inlay for tool and GDE 18V-16 (1 600 A00 HP2), 2 x battery ProCORE18V 5.5Ah (1 600 A02 149)
Specificaties
Aantal slagen bij nominaal toerental
0 - 4350 bpm
Accucapaciteit
5.5 Ah
Accuspanning
18.0 V
Boor-Ø beton met hamerboor
4 - 26 mm
Boor-Ø beton met hamerboor, tot
26 mm
Boor-Ø beton met hamerboor, van
4 mm
Gereedschapshouder
SDS plus
Max. boor-Ø hout
30 mm
Max. boordiameter metaal
13 mm
Meetonzekerheid k (beitelen in beton)
1.5 m/s²
Meetonzekerheid k (hamerboren in beton)
1.5 m/s²
Nenndrehzahl, bis zu
980 min-1
Nenndrehzahl, von
0 min-1
Nominale toerental
0 - 980 min-1
Optimaal toepassingsgebied Beton met hamerboren
8 - 16 mm
Slagenergie (volgens EPTA 05/2016)
2.6 J
Trillingsemissie ah [beitelen in beton]
9.6 m/s²
Trillingsemissie ah [hamerboren in beton]
15.2 m/s²
Verpackungsabmessungen (Breite x Länge x Höhe)
360 x 445 x 255 mm
Werkzeugabmessungen (Länge)
364 mm
