Beschrijving
Cordless Rotary Hammer with SDS plus GBH 18V-28 CF, Bosch’s cordless GBH 18V-28 CF Professional is for those who desire corded performance with cordless freedom. This rotary hammer has a powerful brushless motor delivering 3.3 J impact energy from its proven striking mechanism. The easy-to-read HMI displays the tool status and allows the user to choose between three different work modes (Auto, Favorite, Soft) for perfect control in every job and the toolless, quick-change chuck reduces tool downtime. With the como module (GCY 42) installed, the GBH 18V-28 CF can connect to Bosch’s Toolbox app to further adjust the setting to suit user needs. Vibration Control, KickBack Control, and compatibility with the GDE 18V-16 for dustless drilling, provides a comprehensive range of user protection features. This rotary hammer is ideal for hammer drilling in concrete, stone, and masonry. It is compatible with all batteries and chargers in the Bosch Professional 18V System. For a dust-free and safer work environment, the GDE 18V-16 Professional dust extractor can be easily attached. Also compatible with AMPShare, the multi-brand battery alliance. It also features a storage hook and an LED light. L-BOXX 238 (1 600 A01 2G2), L-BOXX inlay (1 600 A02 SJ3), SDS plus quick-change chuck (2 608 572 213), Dust extraction system GDE 18V-16 Professional (1 600 A00 51M), Quick charger GAL 1880 CV (1 600 A00 B8G), 2 x battery ProCORE18V 8.0Ah (1 600 A01 6GK), 1 x Bluetooth Low Energy module GCY 42 Professional (1 600 A01 3WF), Auxiliary handle (2 602 025 191), Depth gauge (1 613 001 009), Cleaning cloth (1 619 200 413), Grease tube (spare part number 1 615 430 010)
Specificaties
Aantal slagen bij nominaal toerental
4220 bpm
Accuspanning
18.0 V
Boor-Ø beton met hamerboor
4 - 28 mm
Boor-Ø beton met hamerboor, tot
28 mm
Boor-Ø beton met hamerboor, van
4 mm
Gereedschapshouder
SDS plus
Gewicht exkl. Akku
3.4 kg
Max. boor-Ø hout
30 mm
Max. boordiameter metaal
13 mm
Meetonzekerheid k (beitelen in beton)
1.5 m/s²
Meetonzekerheid k (boren in metaal)
1.5 m/s²
Meetonzekerheid k (hamerboren in beton)
1.5 m/s²
Meetonzekerheid k (schroeven)
1.5 m/s²
Optimaal toepassingsgebied Beton met hamerboren
8 - 18 mm
Slagenergie (volgens EPTA 05/2016)
3.3 J
Trillingsemissie ah [beitelen in beton]
9.0 m/s²
Trillingsemissie ah [boren in metaal]
2.5 m/s²
Trillingsemissie ah [hamerboren in beton]
14.0 m/s²
Trillingsemissie ah [schroeven]
2.5 m/s²
Verpackungsabmessungen (Breite x Länge x Höhe)
365 x 442 x 260 mm
Werkzeugabmessungen (Länge)
392 mm
