Beschrijving
Cordless Rotary Hammer BITURBO with SDS max GBH 18V-40 C, The GBH 18V-40 C Professional offers corded performance thanks to its BITURBO Brushless technology providing powerful 9.0 J impact energy. Cordless freedom with ProCORE18V batteries allows fast drilling up to 40 mm and chisel works even in tough environments. It provides an optimal power-to-weight ratio due to an improved impact mechanism and highly capable drive train. In addition to the overload clutch the GBH 18V-40 C offers KickBack Control, which senses sudden loss of tool control. In case of e.g. a canted drill it instantly shuts the cordless rotary hammer down in order to minimise hand and arm injuries. The GBH 18V-40 C Professional is compatible with all Bosch Professional 18V batteries and chargers (Professional 18V system). To reach the maximum power in concrete, stone, and masonry, choose a ProCORE18V battery ≥ 5.5 Ah. Also compatible with AMPShare, the multi-brand battery alliance. A user interface with Bluetooth connectivity displays the real-time status of the tool. Different working modes can be selected and optionally configured via Bosch Toolbox app. It also features Soft Start technologies as Electronic Precision Control (EPC) and Adaptive Speed Control (ASC) for comfortable and precise work processes when drilling and chiselling, an LED light, variable speed, lock-on button, and Vario-Lock. XL-BOXX (1 605 438 1JH), 2 x battery ProCORE18V 5.5Ah (1 600 A02 149), Quick charger GAL 1880 CV (1 600 A00 B8G), Machine cloth, Grease tube (spare part number 1 615 430 010), Auxiliary handle (1 607 031 2E7)
Specificaties
Aantal slagen bij nominaal toerental
0 - 3130 bpm
Accuspanning
18.0 V
Boor-Ø beton met hamerboor
12 - 40 mm
Boor-Ø beton met hamerboor, tot
40 mm
Boor-Ø beton met hamerboor, van
12 mm
Gereedschapshouder
SDS max
Gewicht exkl. Akku
7 kg
Meetonzekerheid k (beitelen in beton)
1.5 m/s²
Meetonzekerheid k (hamerboren in beton)
1.5 m/s²
Nenndrehzahl, bis zu
360 min-1
Nenndrehzahl, von
0 min-1
Nominale toerental
0 - 360 min-1
Optimaal toepassingsgebied Beton met hamerboren
18 - 32 mm
Slagenergie (volgens EPTA 05/2016)
9 J
Trillingsemissie ah [beitelen in beton]
7.0 m/s²
Trillingsemissie ah [hamerboren in beton]
7.5 m/s²
Verpackungsabmessungen (Breite x Länge x Höhe)
395 x 607 x 179 mm
Werkzeugabmessungen (Länge)
502 mm
