Beschrijving
Cordless Random Orbit Sander GEX 12V-125, The GEX 12V-125 Professional random orbit sander is the compact solution for always-on-the-go professionals. Its outstanding balance close to the workpiece and the supreme ergonomics of the palm rest and grip ensure optimal tool control. Defined by its lean and compact design, this 12 V random orbit sander makes sure to reach into tight corners. Its intuitive operating concept makes handling easy. The cordless GEX 12V-125 Professional is intended for basic sanding, in-between sanding, lacquer removal, and finishing surfaces. It is applicable on wood, veneer, lacquer, and filler, as well as mineral and acrylic. It is compatible with the Professional 12V system as well as Bosch’s Click & Clean dust extraction system. The GEX 12V-125 Professional also features a dust bag, speed selection, battery status indicator, a brushless motor, and a 125-mm sanding pad fitted with a hook-and-loop system for fastening sanding sheets. Sanding pad (125 mm) (2 608 000 714), 1 x sanding sheet C430, Expert for Wood + Paint, 120 (available separately as set of 5: 2 608 605 643), Dust bag (2 608 000 715)
Specificaties
Accuspanning
12.0 V
Excentriciteit
1.25 mm
Gewicht exkl. Akku
1.0 kg
Hulpstuk voor schuurmateriaal
Klittenband
Leerlaufdrehzahl, bis zu
10000 U/min
Leerlaufdrehzahl, von
6000 U/min
Meetonzekerheid k (massief hout schuren)
1.5 m/s²
Onbelast toerental
6000 - 10000 U/min
Schuurschijf diameter
125 mm
Trillingsemissie ah [massief hout schuren]
2.2 m/s²
Trillingskring diameter
2.5 mm
Trilsnelheid
12000 - 20000 min-1
Trilsnelheid vanaf
12000 min-1
Trilsnelheid, tot
20000 min-1
Verpackungsabmessungen (Breite x Länge x Höhe)
192 x 233 x 127 mm
Werkzeugabmessungen (Länge)
194 mm
