Beschrijving
Cordless Random Orbit Sander GEX 18V-125, The GEX 18V-125 Professional random orbit sander provides users with optimal tool control, specifically, when working on larger surfaces. The random orbit sander´s outstanding balance close to the workpiece as well as the supreme ergonomics of its palm rest and grip offer optimal tool control. Fast work progress and a longer tool lifetime are ensured by its brushless motor and Bosch’s Professional 18V system. The GEX 18V-125 Professional can be easily and intuitively operated. This cordless random orbit sander is intended for basic sanding, in-between sanding, lacquer removal, and finishing surfaces. It is applicable on wood, veneer, lacquer, and filler, as well as mineral and acrylic. It is compatible with the Professional 18V system as well as Bosch’s Click & Clean dust extraction system. Also compatible with AMPShare, the multi-brand battery alliance. The GEX 18V-125 Professional also features a dust bag, speed selection, and a 125-mm sanding pad fitted with a hook-and-loop system for fastening sanding sheets. Sanding pad (125 mm) (2 608 000 714), 1 x sanding sheet C430, Expert for Wood + Paint, 120 (available separately as set of 5: 2 608 605 643), Dust bag (2 608 000 715), L-BOXX 136 (1 600 A01 2G0)
Specificaties
Accuspanning
18.0 V
Excentriciteit
1.25 mm
Gewicht exkl. Akku
1.1 kg
Gewicht inclusief accu
1.6 kg
Hulpstuk voor schuurmateriaal
Klittenband
Leerlaufdrehzahl, bis zu
10000 U/min
Leerlaufdrehzahl, von
6000 U/min
Meetonzekerheid k (massief hout schuren)
1.5 m/s²
Onbelast toerental
6000 - 10000 U/min
Schuurschijf diameter
125 mm
Trillingsemissie ah [massief hout schuren]
2.2 m/s²
Trillingskring diameter
2.5 mm
Trilsnelheid
12000 - 20000 min-1
Trilsnelheid vanaf
12000 min-1
Trilsnelheid, tot
20000 min-1
Verpackungsabmessungen (Breite x Länge x Höhe)
360 x 445 x 155 mm
Werkzeugabmessungen (Länge)
224 mm
