Beschrijving
Cordless Combi GSB 12V-35, The ideal combination of compactness, productivity and performance in the 12V class: the brushless GSB 12V-35 Professional cordless combi drill. With up to 26,250 rpm, it delivers the highest impact rate in the 12V category, enabling powerful impact drilling of up to Ø10 mm in masonry. Its compact design allows perfect handling and easy operation – even in challenging working situations. With its high rotation speed of 1,750 rpm, this true all-rounder can be used for a broad variety of jobs. It is suitable for impact drilling, drilling and screwdriving into a wide range of materials. It is compatible with all Bosch Professional 12V and 10.8V batteries and chargers. 1/2 L-BOXX inlay for tool and charger (1 600 A00 2V2), Cardboard box, 1 x belt clip, 1 x bit holder
Specificaties
Aantal slagen, max.
26250 bpm
Accu type
Lithium-ion
Accuspanning
12.0 V
Bohr-Ø Holz, max.
32 mm
Boor-Ø metselwerk, max.
10 mm
Boor-Ø staal, max.
10 mm
Draaimoment (zacht/hard/max.)
20/35/- Nm
Draaimomentniveaus
20+1
Draaimomentniveaus (extra)
1
Draaimomentniveaus (standaard)
20
Drehmoment (hart)
35 Nm
Drehmoment (weich)
20 Nm
Gewicht exkl. Akku
0.8 kg
Klembereik boorhouder, min./max.
0.8 / 10 mm
Klembereik, max.
10.0 mm
Klembereik, min.
0.8 mm
Meetonzekerheid k (boren in metaal)
0.0 m/s²
Meetonzekerheid k (schroeven)
0.0 m/s²
Meetonzekerheid k (slagboren in metselwerk)
1.5 m/s²
Onbelast toerental (1e versnelling / 2e versnelling)
0 - 460 / 0 - 1750 min-1
Onbelast toerental, 1e versnelling, tot
460 min-1
Onbelast toerental, 1e versnelling, uit
0 min-1
Onbelast toerental, 2e versnelling, tot
1750 min-1
Onbelast toerental, 2e versnelling, van
0 min-1
Schroef Ø, max.
8 mm
Trillingsemissie ah [boren in metaal]
1.5 m/s²
Trillingsemissie ah [klopboren in metselwerk]
14.5 m/s²
Trillingsemissie ah [schroeven]
1.5 m/s²
Verpackungsabmessungen (Breite x Länge x Höhe)
235 x 340 x 110 mm
