Beschrijving
Cordless Orbital Sander GSS 18V-13, The GSS 18V-13 Professional offers optimal control on larger surfaces. This is achieved through an excellent tool balance, with the centre of gravity close to the workpiece and the superior ergonomics of the palm rest and grip. Its brushless motor and Bosch’s Professional 18V System ensure fast work progress - recommended battery is the ProCORE18V 4.0Ah. It can be easily operated thanks to its intuitive concept and interchangeable sanding plate system. The GSS 18V-13 Professional is intended for basic sanding, in-between sanding, lacquer removal, and finishing surfaces. It is applicable on wood, veneer, lacquer, and filler, as well as mineral and acrylic. It is compatible with the Bosch Click & Clean dust extraction system and the Professional 18V system. Also compatible with AMPShare, the multi-brand battery alliance. It features a dust bag, speed selection and interchangeable sanding plates in three different sizes fitted with a hook-and-loop system for fastening sanding sheets. L-BOXX 136 (1 600 A01 2G0), Dust bag (2 608 000 715), Base plate, 80 x 130 mm (2 608 601 447) with sanding plate (2 608 601 444), Delta base plate, 100 x 150 mm (2 608 601 448) with sanding plate (2 608 601 445), Base plate, 113 x 101 mm (2 608 601 446) with sanding plate (2 608 601 443), 1 x sanding sheet C470, Best for Wood + Paint, 120 (available separately as set of 10: 2 608 607 232), 1 x sanding sheet C470, Best for Wood + Paint, 120 (available separately as set of 10: 2 608 607 458), 1 x sanding sheet C470, Best for Wood + Paint, 120 (available separately as set of 10: 2 608 901 117), Hole punch (2 608 000 652)
Specificaties
Accuspanning
18.0 V
Delta schuurplateau met klittenband, breedte
100 mm
Delta schuurplateau met klittenband, lengte
150 mm
Gewicht exkl. Akku
1.1 kg
Leerlaufdrehzahl, bis zu
10000 U/min
Leerlaufdrehzahl, von
6000 U/min
Meetonzekerheid k (plaatmaterial)
1.5 m/s²
Onbelast toerental
6000 - 10000 U/min
Schuurplateau met klittenband en klem, breedte
110 mm
Schuurplateau met klittenband en klem, lengte
100 mm
Schuurplateau, breedte
80 mm
Schuurplateau, lengte
130 mm
Trillingsemissie ah [plaatmateriaalslijpen]
3.4 m/s²
Trillingskring diameter
1.6 mm
Trillingsniveau bij onbelast
12000 - 20000 min-1
Trillingssnelheid bij onbelast, tot
20000 min-1
Trilsnelheid bij onbelast vanaf
12000 min-1
Verpackungsabmessungen (Breite x Länge x Höhe)
357 x 442 x 151 mm
