Beschrijving
Cordless Jigsaw GST 18V-155 BC, GST 18V-155 BC Professional (with bow handle) comes with brushless motor and well-balanced tool design. The top handle gripping area and its variable speed trigger ensure perfect tool control. Its saw blade guidance prevents blade bending even in small curves and supports work with perfect precision. The tool is compatible with external dust extraction. Its large saw blade ejection lever and the drop control ensure increased user health and safety protection. It is ideal for curved and cross cuts in solid wood, chipboard, and wood composites as well as in thicker or harder materials. It is compatible with guide rails via adapter and with all Bosch Professional 18V batteries and chargers (Professional 18V System). Also compatible with AMPShare, the multi-brand battery alliance. The tool comes with a robust, die-cast aluminium base plate with two fixing points for increased stability and safety. Its connectivity module allows individual speed and light settings and provides important tool information. 1 x jigsaw blade T 144 DP, Precision for Wood (available separately as set of 3: 2 608 633 A31), 1 x jigsaw blade T 308 BP, Precision for Wood (available separately as set of 3: 2 608 667 399), Anti-splinter guard (spare part number 1 600 A02 08K), Dust extraction nozzle (spare part number 1 600 A01 C3Z), Dust extraction hood (spare part number 1 600 A01 T4N)
Specificaties
Aantal slagen bij onbelast toerental
0 - 3800 min-1
Aantal slagen bij onbelast toerental vanaf
0 min-1
Aantal slagen bij onbelast toerental, tot
3800 min-1
Accuspanning
18.0 V
Gewicht exkl. Akku
2 kg
Meetonzekerheid k (zagen van hout)
1.5 m/s²
Meetonzekerheid k (zagen van metaalplaat)
1.5 m/s²
Slaghoogte
26 mm
Trillingsemissie ah [Zagen van plaatmetaal]
5.0 m/s²
Trillingsemissie ah [zagen van hout]
8.0 m/s²
Verpackungsabmessungen (Breite x Länge x Höhe)
266 x 272 x 90 mm
Zaagdiepte in aluminium
20 mm
Zaagdiepte in hout
155 mm
Zaagdiepte in ongelegeerd staal
10 mm
