Beschrijving
Cordless Drywall Screwdriver GTB 12V-11, The GTB 12V-11 Professional is a cordless compact drywall screwdriver for occasional drywall applications in the 12 V category. It features a compact and lightweight design of 0.9 kg with 2.5 Ah and an ergonomic grip circumference for comfortable handling, even in narrow workspaces. It also has a powerful and compact 12 V drive train capable of fixing up to 1,200 screws per (2.5 Ah) battery charge. For a long tool lifetime, the drywall screwdriver features Bosch’s brushless motor technology with Electronic Motor Protection and a motor brake. This tool is intended for fastening drywall screws into materials such as wood and metal but is also optimised for attaching plasterboard. It is compatible with all Bosch Professional 12V batteries and chargers (Professional 12V System) as well as with the MA 55 Professional screw gun magazine attachment. The GTB 12V-11 Professional features Bosch’s brushless motor technology with Electronic Motor Protection and a motor brake. It also has an Autolock, exchangeable depth stop, reverse mode, and speed selection. L-BOXX 102 (1 600 A01 2FZ), 1 x screwdriver bit PH 2, 1/2 L-BOXX inlay for charger and battery, 1/2 L-BOXX inlay for tool (1 600 A00 3RB)
Specificaties
Accuspanning
12.0 V
Draaimoment, max. (hard/zacht)
3 Nm
Draaimoment, max. (zacht)
3 Nm
Gereedschapshouder
1/4'' zeskant uni
Gewicht exkl. Akku
0.7 kg
Gewicht inclusief accu
0.9 kg
Leerlaufdrehzahl, bis zu
3000 min-1
Leerlaufdrehzahl, von
0 min-1
Meetonzekerheid k (schroeven)
0.5 m/s²
Onbelast toerental
0 - 3000 min-1
Schroef Ø, max.
4 mm
Trillingsemissie ah [schroeven]
1.5 m/s²
Verpackungsabmessungen (Breite x Länge x Höhe)
360 x 450 x 120 mm
