Beschrijving
Random Orbit Sander GET 75-150, The GET 75-150 Professional is Bosch’s 150-mm corded active-driven random orbit sander with outstanding tool control and handling. It is designed with a perfectly ergonomic palm rest and a handle with a gripping circumference of only 18 cm for best tool control. Thanks to its multi-hole sanding pad, all sanding sheets irrespective of the hole pattern can be conveniently fitted and the dust extraction is significantly increased. It features an extremely powerful 750 W motor and direct driven pad rotation that deliver a up to 45% higher removal rate. This corded sander is intended for basic sanding, in-between sanding, lacquer removal, finishing, and polishing surfaces. It is applicable on wood, veneer, lacquer, and filler, as well as mineral and acrylic. It is compatible with the Bosch Click & Clean dust extraction system. The GET 75-150 also includes constant speed, direct-driven mode, an edge protector, a 150 mm sanding pad fitted with a hook-and-loop system for fastening sanding sheets and speed selection. Sanding pad (150 mm) (2 608 900 007), L-BOXX 238 (1 600 A01 2G2), 1 x sanding sheet M480, Best for Wood + Paint, 80 (available separately as set of 5: 2 608 621 162), 1 x sanding sheet M480, Best for Wood + Paint, 120 (available separately as set of 5: 2 608 621 164), 1 x sanding sheet M480, Best for Wood + Paint, 180 (available separately as set of 5: 2 608 621 166), Guard ring for 150 mm (2 607 017 497), Auxiliary handle incl. screw (2 607 017 500), Suction socket for 150 mm (2 607 017 499), Hex key
Specificaties
Excentriciteit
2.25 mm
Gewicht
2.6 kg
Hulpstuk voor schuurmateriaal
Klittenband
Leerlaufdrehzahl, bis zu
7300 min-1
Leerlaufdrehzahl, von
3300 min-1
Meetonzekerheid k (massief hout schuren)
1.5 m/s²
Nominaal ingangsvermogen
750 W
Onbelast toerental
3300 - 7300 min-1
Schuurschijf diameter
150 mm
Schuurschijf-rotatiesnelheid
290 - 640 min-1
Schuurschijf-rotatiesnelheid, tot
640 min-1
Schuurschijf-rotatiesnelheid, vanaf
290 min-1
Spanning, elektrisch
230 V
Trillingsemissie ah [massief hout schuren]
6.5 m/s²
Trillingskring diameter
4.5 mm
Trilsnelheid
6600 - 14600 min-1
Trilsnelheid vanaf
6600 min-1
Trilsnelheid, tot
14600 min-1
Verpackungsabmessungen (Breite x Länge x Höhe)
360 x 441 x 256 mm
Werkzeugabmessungen (Länge)
417 mm
