Beschrijving
Laser Measure GLM 150-27 C, This robust outdoor laser measure has a digital camera viewfinder with a zoom function for accurately measuring distances up to 150 m. Measurements and pictures are automatically saved and easy to read thanks to a large, high-contrast 2.8" IPS colour display that rotates between portrait and landscape view. For convenient documentation, all data can be transferred via Bluetooth to the Bosch MeasureOn App or via USB connection to a PC. With IP54 protection, scratch-resistant display glass, and user-friendly interface, this laser measure is the handy all-rounder for demanding jobsites. Architects, construction managers, or HVAC installation professionals will reach for this smart laser measure for its long-distance capability, easy readability, and convenient documentation. The GLM 150-27 C laser measure has an integrated lithium-ion battery, ensuring long operating time and more flexibility. Micro USB cable (2 609 120 670), Protective Bag, Carrying Strap
Specificaties
Aantal opslagwaarden
50
Automatische uitschakeling
5 min
Datenübertragung
Bluetooth 4.2 Low Energy
Digitale richtoptiek
geïntegreerd
Functie wandoppervlak
ja
Gewicht, ca.
0.21 kg
Geïntegreerde hellingsmeting
ja
Indirecte hoogtemeting
ja
Indirecte lengtemeting
ja
Laserdiode
650 nm, < 1 mW
Laserklasse
2
Laserkleur
rood
Maateenheden
m/cm/mm/Ft/Inch/Ft-Inch
Meetbereik
0.08 - 150.00 m
Meetbereik hellingsmeting
0 - 360° (4 x 90°)
Meetnauwkeurigheid (typisch)
± 0,2°* (* plus toepassingsafhankelijke afwijking)
Meetnauwkeurigheid, typ.
± 1,5 mm* (* plus toepassingsafhankelijke afwijking)
Meettijd, max.
4 s
Meettijd, nom.
< 0.5 s
Min/Max meting
ja
Schokbescherming
tot 1 m
Statiefschroefdraad
1/4"
Stof- en spuitwaterbescherming
IP 54
Stroomvoorziening
1 x 3,6 V Li-Ion batterij (3120 mAh)
Timerfunctie
ja
