Beschrijving
Laser Measure GLM 50-22, The GLM 50-22 Professional withstands rough conditions on construction sites. Its IP65 design provides complete protection from dust particles and jets of water, while its shock-absorbing housing brings 1.5-m drop resistance even on hard concrete. With a customisable button, favourite measurement functions or settings can be defined. Its intuitive user interface supports 30 languages and consists of a colour display and Big Numbers Mode for better readability. For self-explaining usage it features a new help function that shows all measurement options. For electricians, HVAC installers, and plumbers, it is ideal when placing and fitting elements on wood, general, or drywall constructions. When used for finishing, it is perfect for painters, floor layers, tilers, or carpenters to calculate material needs. Long battery runtime regardless of whether Alkaline batteries or the optional Li-ion battery pack is used. Protective Bag, Carrying Strap, 2 x 1.5 V LR6 battery (AA)
Specificaties
Aantal opslagwaarden
10
Automatische uitschakeling
5 min
Gewicht, ca.
0.2 kg
Indirecte hoogtemeting
ja
Indirekte Längenmessung
nein
Laserdiode
635 nm, < 1 mW
Laserklasse
2
Laserkleur
rood
Maateenheden
m/cm/mm/Ft/Inch/Ft-Inch
Meetbereik
0.05 - 50.00 m
Meetnauwkeurigheid, typ.
± 1,5 mm* (* plus toepassingsafhankelijke afwijking)
Meettijd, max.
4 s
Meettijd, nom.
< 0.5 s
Min/Max meting
ja
Schokbescherming
tot 1,5 m
Statiefschroefdraad
1/4"
Stof- en spuitwaterbescherming
IP 65
Stroomvoorziening
2 x 1,5 V LR6 (AA)
