Bosch

Metaalboren set HSS-G, ProBox

25 stuks, DIN 338, 135° 1-13 mm Bosch 2.608.587.017
Art.-Nr.: 1272645Leveranciersnummer: 2608587017EAN: 3165140689816

Aantal: ​​ 1 SAPakketgeschikt
Artikel in 131 varianten beschikbaar:
Op korte termijn verkrijgbaar

Beschrijving
The HSS Twist Drill Bit Ground is for drilling through metal with maximum precision. The bit's exposed 135-degree self-centring split-point tip combines active cutting and perfect centring without wandering, delivering maximum precision. The split-point tip also eliminates any need to pre-punch or pilot drill for up to 10 mm. This precision-ground bit made of HSS (high-speed steel) enables up to 40% faster drilling rate and up to 50% lower feed pressure than standard-ground HSS drill bits with chisel edges. This bit is designed for drilling holes in alloyed and non-alloyed steel, cast steel, cast iron, sintered iron, malleable cast iron, non-ferrous metals and hard plastics. The HSS Twist Drill Bit Ground is manufactured to DIN 338. The drill bit is Type N (flute angle) with a 135-degree tip and a diameter tolerance of h8.
Specificaties
Afmeting(en) set
200.0 x 115.0 x 58 mm
Afmeting(en) set, breedte
115.0 mm
Afmeting(en) set, hoogte
58 mm
Afmeting(en) set, lengte
200.0 mm
Diameter
9.5 mm
Totale lengte mm
93 mm
Werklengte
94 mm
