Beschrijving
Rotation Laser GRL 600 CHV, Heavy duty, jobsite-proof – the robust GRL 600 CHV Professional endures even the harshest environments. Its sturdy design offers impact protection and has an IP68 rating against dust and water – including the battery compartment for highly flexible work in bad weather conditions. It provides convenient connectivity, enabling more focused work with less wasted time. Operating the tool is intuitive thanks to its screen and access to the levelling remote app that visualises all functions, including a dual slope setting, to save valuable time. This highly accurate laser has a long runtime, both with the 18V battery system and alkaline batteries included for continuous working. Use this tool for exterior applications when determining cut-and-fill excavation work, concrete forms, landscaping, and façade work. The GRL 600 CHV also features a high-quality receiver with a 125-mm reception area, a dual-sided display, and an offset feature in millimetres. Calibrating the tool is quick and easy – follow the step-by-step instructions via the intuitive app to save time and resources and ensure accurate results on every job. Use the handy 'mask mode' available in the app to avoid reflection and interference with other devices on the jobsite. Laser receiver LR 60 Professional (0 601 069 P00), Receiver bracket RB 60 Professional, Remote control RC 6 Professional, 1 x battery ProCORE18V 4.0Ah (1 600 A01 6GB), Quick charger GAL 18V-40 Professional (1 600 A01 9RJ), Battery adapter BA 1 Professional, Wall mount WM 6 Professional, 4 x 1.5 V LR20 battery (D), 4 x 1.5 V LR6 battery (AA), Laser target plate, Laser viewing glasses (red) (spare part number 1 608 M00 05B), Carrying case
Specificaties
Accuspanning
18 V
Bedrijfstemperatuur
-10 - 50 °C
Bedrijfstijd, max.
70 h
Compatibele laserontvanger
LR 60
Gewicht met 4.0Ah batterij
4.3 kg
Gewicht met alkalinebatterijen
4.6 kg
Laserdiode
630 - 650 nm, < 1mW
Laserklasse
2
Nivelleernauwkeurigheid
± 3,0 mm bij 30 m* verticaal (* plus toepassingsafhankelijke afwijking)
Opslagtemperatuur
-20 - 50 °C
Projectie
1 x 360° lijn
Rotatiesnelheid
150/300/600 min?1
Statiefschroefdraad
2 x 5/8"
Stof- en spuitwaterbescherming
IP 68
Stroomvoorziening
4 x D-batterijen
Werkbereik met ontvanger
tot 600 m (diameter)
Werkbereik met ontvanger, teken
tot
Werkbereik met ontvanger, waarde
600 m
Werkbereik zonder ontvanger
tot 60 m (diameter)
Werkbereik zonder ontvanger, teken
tot
Werkbereik zonder ontvanger, waarde
60 m
Zelfnivelleringsbereik
±8.5% (±5°)
