Beschrijving
The S 1122 EF Flexible for Metal Reciprocating Saw Blade is optimised for flush cutting in metal. Its 225 mm length and standard-gauge material thickness of 0.9 mm enable excellent flush cuts. Moreover, cutting steel materials with most common wall thicknesses is possible thanks to the blade’s fine tooth pitch (1.4 mm). Made of BIM (bi-metal), the blade is suitable for cutting regular-strength steel materials, while its fine tooth pitch is ideal for use on pipes and profiles with a wall thickness of 1.5 mm to 4 mm. The blade’s standard length of 225 mm provides a cutting capacity of up to 175 mm.
Specificaties
Abkürzung für Blattmaterial
BIM
Blattmaterial
BI-METAL
Bleche, dünn
1.5-4 mm
Breedte
19 mm
Dicke
0.9 mm
Dikte
0,9 mm
Empfohlene max. Materialstärke
4 mm
Empfohlene min. Materialstärke
1.5 mm
Körpermaterial
HCS
Materiaal
BIM
Max. Schnittleistung
175 mm
Profile, Rohre: geschlossen
<175 mm
Profile, Rohre: offen
<175 mm
St. per kaart
25
Tandafstand TPI
18
Tandsteek
1,4 mm
Totale lengte
225 mm
Type
S 1122 EF
Versie
ingesteld, gefreesd
Zahnausführung
geschränkt, gefräst
